Tumble Dryer - Display Board 15Kg,30Kg - Dryer - NDBD
₹ 15,200.00
Availability:
In stock
SKU
NDBD
Details
The NDBD Display Board is a complete control panel display unit specifically designed for 15KG and 30KG Industrial Tumble Dryer models. This advanced display board features a built-in 220V to 12V transformer that powers internal relay circuits, while the relay outputs control 220V functions such as heater operation and blower motor activation. Serving as the main control interface, it provides precise cycle control, temperature management, and system monitoring for optimal drying performance.
• Dual Capacity Compatibility: Designed for both 15KG and 30KG tumble dryer models.
• Built-In 220V to 12V Transformer: Powers internal control circuits safely.
• Relay Control System: 12V relays control 220V outputs for heaters and motors.
• 220V Output Control: Manages high-power components (heater, blower motor).
• User Control Interface: Cycle selection, temperature adjustment, timer settings.
• Status Display: Visual indication of dryer operation and cycle progress.
• Integrated Control System: Central interface for all dryer functions.
• Industrial Durability: Built for continuous laundry operation.
• Safety Isolation: 12V control circuits isolated from 220V power circuits.
• Control panel replacement for 15KG and 30KG industrial tumble dryers.
• Complete control system upgrade for laundry drying equipment.
• Replacement for damaged or malfunctioning display boards with transformer.
• Control system maintenance including relay and transformer functions.
| Model Name | NDBD |
| Category | Display Board / Control Panel |
| Input Voltage | 220V AC |
| Control Voltage | 12V DC (via built-in transformer) |
| Relay Outputs | 220V for heater and blower motor control |
| Compatible Machine | STDME 15, STDME 30, STDME 50 |
| Function | Complete Control Interface with Power Management |
• Complete Power Management: Built-in transformer and relay system.
• Dual Capacity Support: One board fits both 15KG and 30KG dryer models.
• Safe Control Design: 12V control circuits isolated from 220V power.
• High-Power Control: Relays handle heater and motor 220V switching.
• Industrial Grade: Built for continuous laundry operation.
• Easy Replacement: Direct swap including transformer and relay functions.
• OEM Quality: Matches original equipment specifications.
• Cost-Effective: All-in-one control solution.
1 x Complete Display Board (NDBD) with built-in transformer and relay system
