Curve Bed Press - Limit Switch Az-7312 - SFLM 7312
₹ 1,100.00
Availability:
In stock
SKU
SFLM 7312
Details
The TZ-7312 Limit Switch is a heavy-duty Single-Pole Double-Throw (SPDT) industrial safety and position switch with 3 terminals: Common (C), Normally Open (NO), and Normally Closed (NC). Rated for 380V insulation voltage (Ui) and 10A thermal current (Ith), this versatile switch allows wiring flexibility for different control logic needs. It's widely used in Washer Extractors, Pressing Machines, Hydro Extractors, Dryers, and various industrial machinery for position sensing, safety interlocks, and end-of-travel detection.
• High Voltage Rating: Ui 380V, Ue 250V AC/DC
• Dual Use Ratings: AC-15: 250V 10A | DC-13: 250V 0.3A
• 10A Thermal Current: For continuous industrial duty
• SPDT Configuration: 3 terminals -- C, NO, NC -- choose your wiring
• Universal Machine Application: Used across laundry and industrial equipment
• Hybrid Construction: Stainless steel body with plastic actuator
• 35mm Standard Size: Fits most industrial machine panels
• Screw/Lug Terminals: Three clearly marked terminals
• Built for Tough Conditions: Resists vibration, steam, humidity, and heat
• Door/lid safety interlocks in Washer Extractors (wire NC for safety circuits)
• Basket position sensing in Hydro Extractors (wire NO or NC as needed)
• Head/tooling end-of-travel in Pressing Machines
• Safety stops in Industrial Dryers and Finishers
• General machinery position and limit detection
| Model Name | SFLM 7312 |
| Category | LIMIT SWITCH |
| Switch Type | Single-Pole Double-Throw (SPDT) |
| Terminals | 3 -- Common (C), Normally Open (NO), Normally Closed (NC) |
| Insulation Voltage (Ui) | 380V |
| Thermal Current (Ith) | 10A |
| AC Rating (AC-15) | 250V, 10A |
| DC Rating (DC-13) | 250V, 0.3A |
| Phase | SINGLE |
| Connector Type | Screw/Lug |
| Material | Stainless Steel & Plastic |
| Size | 35mm diameter |
| Price | ₹1,100 |
| Compatible Machine | SCBPS 52, SCBPE 52, SCCHLPS, SBHLPS |
• Wiring Flexibility: Use as NO or NC by connecting to different terminals
• Wide Machine Compatibility: Fits Washer Extractors, Pressing Machines, Extractors, Dryers, etc.
• Certified Switching Ratings: AC-15 and DC-13 compliant
• Industrial Durability: Built for laundry and industrial environments
• One Switch, Two Functions: Can be used in both safety and position circuits
• 1 x TZ-7312 SPDT Limit Switch
