The SFNOE Element NO is a terminal adapter/connector block designed to connect push buttons in laundry press control circuits. It features two screw terminals for 220V wire connections and is configured as Normally Open (NO), meaning it completes the circuit only when the push button is pressed. This adapter provides secure electrical connections between the push button and the machine's control wiring, with plastic housing for insulation and safety.
• Terminal Adapter Function: Connects push button to control wiring
• NO Configuration: Normally Open -- closes circuit when button pressed
• 220V Rating: Suitable for standard industrial control voltage
• Screw Terminal Connections: Two screws for secure wire connections
• Mounting Screw: Additional screw for attaching to push button body
• Plastic Housing: Insulated and moisture-resistant
• Compact Design: 2.5x2mm profile fits standard push button backs
• Easy Installation: Simple screw-terminal wiring
• Single Phase Use: Standard industrial control circuits
• Wiring adapter for push buttons in laundry press control panels
• Terminal connection for start/stop buttons in industrial machines
• Electrical interface between push buttons and machine wiring
• Replacement for damaged or lost push button terminal blocks
| Model Name | SFNOE |
| Category | TERMINAL ADAPTER / CONNECTOR |
| Voltage | 220V AC |
| Current | 15A |
| Configuration | Normally Open (NO) |
| Terminal Type | Screw/Lug |
| Number of Terminals | 2 (for wire connections) + mounting screw |
| Material | Plastic |
| Size | 2.5x2mm |
| Compatible Machine | SCBPS 52, SCBPE 52, SDHP 15, SDHP 30, SCCHLPS, SBHLPS |
• Secure Connections: Screw terminals ensure reliable electrical contact
• Push Button Compatibility: Designed specifically for laundry press buttons
• Standard Voltage: 220V for most industrial control systems
• Easy to Install: Simple screw-in wiring
• Cost-Effective: Affordable replacement for damaged adapters
• 1 x Element NO Terminal Adapter (SFNOE) with screws
